Operating voltage

230VAC or 120VAC

Heating element

PTC resistor - temperature limiting

Temperature safety cut-out

to protect against overheating in case of fan failure, automatic reset

Axial fan, ball bearing

airflow 160m³/h, free flow. service life 50,000h at +25°C (+77°F)

Connection

2-pole max. 2.5mm², clamping screw with strain relief, torque 0.8Nm max.

Casing

plastic according to UL94 V-0, black

Mounting

screw fixing (M6)

Fitting position

vertical airflow (air outlet up) – other fitting positions possible

With Thermostat

With thermostat to control temperature

With on/off switch

Can manual power on and off

Dimensions

182 x 160 x 120mm

Weight

approx. 1.3kg

Operating/Storage temperature

-45 to +70°C (-49 to +158°F)

Operating/Storage humidity

max. 90% RH (non-condensing)

Protection type/Protection class

IP20 / II (double insulated)
